124
4 - CONTROL
The default setting in the automatic mode of the heating system is
Combustion control.
No. Display Description
4-01 Type of boiler control
Fixed value
Combustion ctrl.
Comb+output ctrl.
Log wood
• Type of control for the combustion
"Fixed value" mode
“Combustion ctrl.” mode
“Combustion and output control” mode
“Log wood” emergency operation
4-02 Control
Fixed value
Dosage
( 20) 20%
• Fuel quantity for “Fixed value” type of control
Option for setting a fixed fuel quantity for “Fixed value”
operation.
(0 - 100 %)
4-03 Control
Fixed value
Primary air
( 30) 30%
• Primary air volume for “Fixed value” type of control
Option for setting a fixed primary air volume for “Fixed
value” operation.
(0 - 100 %)
4-04 Control
Fixed value
Secondary air
( 10) 10%
• Secondary air volume for “Fixed value” type of control
Option for setting a fixed secondary air volume for “Fixed
value” operation. (0 - 100 %)
4-05 Control
Fixed value
Flue gas fan
( 30) 30%
• Flue gas fan setting for “Fixed value”
Setting option for the speed of a flue gas fan for “Fixed
value” operation.
(0 - 100 %)
4-06 Control
Combustion control
Chamber set temp.
( 550) 550°C
• Preset combustion chamber temperature for nominal
load
Set the target temperature for the combustion chamber
at nominal load.
Only possible for “Combustion control” mode.
(200 - 1000 °C)
4-07 Control
PID_1 comb.cham.temp
Amplification
(P)
( 7.0) 7.0
• Amplification factor for combustion chamber tempe-
rature
For “Combustion and output control” mode.
4-08 Control
PID_1 comb.cham.temp
Lag time (I)
(300) 300s
• Lag time of combustion chamber temperature
For “Combustion and output control” mode.
Table 6/6 - System level / 4 - Control
