HDG Compact 25 - Page 125

6 Using the heating system – Structure of the menus
125
4-09 Control
PID_1 comb.cham.temp
Advance time (D)
( 0.0) 0.0s
• Advance time of combustion chamber temperature
For “Combustion and output control” mode.
4-11 Control
PID_1 comb.cham.temp
Minimum
( 300) 300°
• Minimum combustion chamber temperature
For “Combustion and output control” mode.
4-12 Control
PID_1 comb.cham.temp
Maximum
( 550) 550°
• Maximum combustion chamber temperature
For “Combustion and output control” mode.
4-13 Control
PID_2 Fuel
Amplification
(P)
( 0.04) 0.04
• Amplification factor for fuel quantity
For “Combustion and output control” mode.
4-14 Control
PID_2 Fuel
Lag time (I)
(257.3) 257.3s
• Lag time for fuel quantity
For “Combustion and output control” mode.
4-15 Control
PID_2 Fuel
Advance time (D)
( 0.0) 0.0s
• Advance time for fuel quantity
For “Combustion and output control” mode.
4-17 Control
PID_2 Fuel
Minimum
( 10.0) 10.0%
• Minimum fuel quantity
For “Combustion and output control” mode.
(0 - 100 %)
4-18 Control
PID_2 Fuel
Maximum
( 20.0) 20.0%
• Maximum fuel quantity
For “Combustion and output control” mode.
(0 - 100 %)
4-20 Control
R-1 Primary air
at min fuel
( 30.0) 30%
• Primary air volume for minimum fuel quantity
For “Combustion and output control” mode.
(0 - 100 %)
4-21 Control
R-1 Primary air
at max fuel
( 35.0) 35%
• Primary air volume for maximum fuel quantity
For “Combustion and output control” mode.
(0 - 100 %)
No. Display Description
Table 6/6 - System level / 4 - Control
