5 Commissioning the system – Procedure
93
h-25 Manual HC
Mixing valve HC 4
Open 0 Close 0
(+) (-)
Mixing valve HC 4
Plus button: Mixing valve is opened
Minus button: Mixing valve is closed
h-26 Manual HC
HCP/Thermostat 4
HCP 4: 0 (+)
Room/VL 4: -20/-50°C
Pumps/Indoor thermostat for heating circuit 4
Plus button: Heating circuit pump 4 switches on/off
h-27 Manual HC
Mixing valve HC 5
Open 0 Close 0
(+) (-)
Mixing valve HC 5
Plus button: Mixing valve is opened
Minus button: Mixing valve is closed
h-28 Manual HC
HCP/Thermostat 5
HCP 5: 0 (+)
Room/VL 5: -20/-50°C
Pumps/Indoor thermostat for heating circuit 5
Plus button: Heating circuit pump 5 switches on/off
h-29 Manual HC
Mixing valve HC 6
Open 0 Close 0
(+) (-)
Mixing valve HC 6
Plus button: Mixing valve is opened
Minus button: Mixing valve is closed
h-30 Manual HC
HCP/Thermostat 6
HCP 6: 0 (+)
Room/VL 6: -20/-50°C
Pumps/Indoor thermostat for heating circuit 6
Plus button: Heating circuit pump 6 switches on/off
h-31 Manual HC
DHW 1
Top/Bottom -50/-50?
DHW pump 1: 0 (+)
DHW 1
Plus button: Hot water pump 1 switches on/off
h-32 Manual HC
DHW 2
Top/Bottom -50/-50?
DHW pump 2: 0 (+)
DHW 2
Plus button: Hot water pump 2 switches on/off
h-33 Manual HC
Collector temp: -50°C
Solar pump 1: 0%
(+) (-)
Solar pump
Plus button: Speed of solar pump is increased
Minus button: Speed of solar pump is reduced
h-34 Manual HC
Solar acc. pump
Acc. pump 1: 0%
(+) (-)
Solar acc. pump
Plus button: Speed of solar accumulator pump is increa-
sed
Minus button: Speed of solar accumulator pump is redu-
ced
No. Display Description
Table 5/7 - Sensors in manual operation
