4.5.1 Set Fire Source Shielded Region
Steps
1. Go to
Conguraon → Local , and enable Display Shield Area.
2. Go to
Conguraon → Event → Smart Event → Fire Source Region Shield .
3. Check Enable Fire Source
Detecon Shield .
4. Select Drawing Mode, and draw the area you want to shield.
In
FOV
Select this mode if the shielded area is in the current scene.
a. Click the PTZ control buons to nd the area you want to shield from the re
detecon.
b. Click Draw Area, and drag the mouse in the live view to draw the area.
c. You can drag the corners of the red rectangle area to change its shape and size.
d. Click Stop Drawing to nish drawing, or click Clear All to clear all of the areas you
set without saving them.
Out
FOV
Select this mode if the shielded area exceeds the current scene.
a. Click Draw Area, and a red cursor displays in live view.
b. Select Vertex NO. 1, and adjust the live view image by clicking the PTZ control
buons.
c. When one corner of the shielded area is on the red cursor, click Set Vertex.
d. Repeat steps b-c to set other three vertexes.
e. Click Stop Drawing to
nish drawing, or click Clear All to clear all of the vertexes
you set.
Note
• Set vertexes clockwise or
anclockwise in sequence.
• The pan angle of set area should be from 2 to 80 degrees, and lt angle should be from 1 to
45 degrees.
• Draw four vertexes again if you want to change the shielded area.
5. Check Display Shield Area to show the shield area on the live view.
6. Click Add to save the re detecon shield, and it will be listed in the Fire Source Detecon
Shield List area; you can select a region and click Delete to delete it from the list; you can also
dene the color of the regions.
7. Click Save.
4.6 Set Smoke
Detecon Parameters
To avoid the potenal smoke damage, you should congure the smoke detecon funcon for
certain areas. The detail
conguraon steps show as below.
Steps
1. Go to Conguraon → Event → Smart Event , select Fire and Smoke Detecon.
