9.1 Basic Specifications
────────────────────────────────────────────────────
Current measurement
range
0.01 mA to 120 mA
Designated value
Average value rectified effective value display ( digital )
Resolution
0.01 mA
（
2mA/8mAranges
）
0.1 mA
（
32 mA range
）
1 mA
（
120 mA range
）
Accuracy
±
3%f.s.
±
20 μA ... for all ranges
( power waveform distortion is less than 5% )
NOTE
Decision method
Window comparator method ( digital setting )
Decision contents UPPER-FAIL: when measured current exceeds the upper level
setting
PASS: when measured current remains between the upper / lower
level settings for set time
LOWER-FAIL: when the measured current is below the lower level
setting
Decision process
Output to the display, beeper sound, signals to EXT I/O for each
decision result
Setting range
0.1 mA - 120 mA ( both upper / lower level value )
Setting resolution
0.1 mA (0.1 mA - 9.9 mA)/ 1 mA
（
10 mA - 120 mA
）
Setting ON
Counts down time from start to preset time
Setting OFF
Shows elapsed time from start
Setting range
0.5 s to 999 s
Setting resolution and
accuracy
0.1 s ( 0.5 s - 99.9 s )
±
50 ms / 1 s ( 100 s - 999 s )
±
0.5 s
Current Detection Section
f.s. (maximum display or scale value, or length of scale)
Signifies the maximum display (scale) value or the length of the scale (in cases
where the scale consists of unequal increments or where the maximum value cannot
be defined).
In general, this is the range value (the value written on the range selector or
equivalent) currently in use.
Decision Function
Timer Section
