Hioki 3158 - Procedure for Saving Data

63
────────────────────────────────────────────────────
5.1 Saving Preset Values
────────────────────────────────────────────────────
1
2
3
5
7
8
9
10
11
12
13
14
A
5.1.1 Procedure for Saving Data
NOTE
To select a preset value to be saved, the unit must be in the READY state. Preset
values cannot be changed in the save screen.
The following four parameters may be saved:
(1) Comparative voltage value
(2) Upper level value
(3) Lower level value
(4) Test time
(1) Displaying the save screen
With the target preset value displayed in the READY state, press
SHIFT
+
keys to shift to the save screen.
In the save screen, the saved data for the file number replaces the target value
displayed in the READY state.
The first saved data displayed is the last data from the previous save screen.
(2) Selecting a file to save
The new data overwrites the previous data. Look for the saved data to be
deleted, using the
/ keys. Use the / keys to switch between upper
and lower level values.
(3) Saving and canceling data
When the saved data to be deleted is displayed, press
SHIFT
+ keys. This
deletes the saved data and saves the value set in the READY state.
After the saving the data, the unit reverts to the READY state.
Press the
STOP
key to revert to the READY state without saving the target
data.
For comparative voltage, the test lower limit, and test time, both ON/OFF settings
and set values used (when on) are saved.
