Hioki 3158 - Procedure for Loading Data

67
────────────────────────────────────────────────────
5.2 Loading Preset Values
────────────────────────────────────────────────────
1
2
3
5
7
8
9
10
11
12
13
14
A
5.2.1 Procedure for Loading Data
Comparative voltage value OFF
（
0.00 kV
）
Upper level value 0.2 mA
Lower level value OFF
（
0.1 mA
）
Test time 0.5 s
NOTE
Before loading, carefully read Section 5.1, "Saving Preset Values" and prepare the
data to be saved. The following are factory-set data.
The following four parameters may be loaded:
(1) Comparative voltage value
(2) Upper level value
(3) Lower level value
(4) Test time
(1) Displaying the load screen
To load the saved data, Press
SHIFT
+ keys in the READY state to shift
to the load screen.
In the load screen, a number for saved data equal to the file preset replaces the
target value displayed in the READY state.
The first saved data displayed is the last data from the previous load screen.
(2) Selecting a file to save
Look for the saved data to be loaded, using the
/ keys.
Use the
/ keys to switch between upper and lower level values
(3) Loading and canceling data
When the saved data to be loaded is displayed, press
SHIFT
+ keys. This
loads the saved data and the unit reverts to the READY state.
Press the
STOP
key to revert to the READY state without loading the target
data.
For comparative voltage, the test lower limit, and test time, both ON/OFF settings
and set values used (when on) are saved.
