Contents
Inspection i
Safety Notes
ii
Notes on Use
iv
Contents and Indications of This Manual
vi
Chapter 1 Overview 1
1.1 Product Introduction 2
1.2 Names and Functions of Parts
3
Chapter 2 Testing Arrangements 7
2.1 Connecting the Protective Ground Terminal 7
2.2 Wearing rubber gloves
8
2.3 Connecting the External I/O Connector
9
2.4 Power Cord Connection
10
2.5 Powering On and Off the Unit
11
2.6 Connecting the 9615 H.V. TEST LEAD
12
2.7 Connecting the REMOTE CONTROL BOX
14
2.8 Installation of the Unit
15
2.9 Connection to the Measured Equipment
16
2.10 Startup Inspection
17
Chapter 3 Testing Method 19
3.1 State of the 3158 and Preset Parameters 20
3.2 Making Testing Arrangements (in READY State)
22
3.2.1 Selecting an Output-Voltage Range 23
3.2.2 Key-lock Function 23
3.2.3 Initial Settings for Optional Functions 24
3.3 Setting the "SETTING" State 25
3.3.1 Setting the Comparative Voltage Value 26
3.3.2 Setting the Upper (Lower) Level Value 27
3.3.3 Setting the Test Time 28
3.3.4 Examples of Settings 29
3.4 Starting a Test 32
3.4.1 Setting the Output Voltage 33
3.4.2 Executing a Test 35
3.4.3 Screening in "TEST State" 37
3.5 PASS or FAIL Determination 38
3.5.1 "PASS" State 38
3.5.2 Screening in "PASS" State 39
3158A981-12
