Hioki 3158 - Page 4

3.5.3 "FAIL" State 40
3.5.4 Screening in "FAIL" State 43
Chapter 4 Optional Functions 45
4.1 PASS Hold Function 48
4.2 FAIL Hold Function
49
4.3 Hold Function
50
4.4 Momentary Out
52
4.5 Double Action
53
4.6 FAIL Mode
54
4.7 RS Command [START]
55
4.8 Inter-lock Function
56
4.9 Voltage Comparator Position
57
4.10 Example of Optional Function Settings
58
4.11 Example of Optional Functions Use
59
Chapter 5 Saving/Loading Preset Values 61
5.1 Saving Preset Values 62
5.1.1 Procedure for Saving Data 63
5.1.2 Example of Saving 64
5.2 Loading Preset Values 66
5.2.1 Procedure for Loading Data 67
5.2.2 Example of Loading 68
Chapter 6 External Interface 71
6.1 External I/O Terminal 71
6.1.1 Signal Line 72
6.1.2 Example of Input Signal Connection 74
6.1.3 Example of Output Signal Connection 76
6.1.4 Inter-lock Function 78
6.1.5 Timing Chart of External I/O Terminal 80
6.2 Buzzer 83
Chapter 7 RS-232C Interface 85
7.1 Specifications 85
7.2 Connection Method
86
7.3 Command Transfer Methods
87
7.4 Command
89
7.5 Transmission and Response Formats
100
7.6 Command Summary
101
