APPENDIX1
────────────────────────────────────────────────────
Appendix 1 9613 REMOTE CONTROL BOX (SINGLE)
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
APP
Ambient operating conditions
0to40℃ (32 to 104
ﾟ
F), 80%RH max. (no condensation)
Ambient storage conditions
-10 to 50℃ (14 to 122
ﾟ
F), 90%RH max. (no condensation)
Operating Environment
Indoors < 2000 mASL (6562 feet)
Dimensions
Approx. 193W x 50H x 30D mm (7.60"W x 1.97"H x 1.18"D)
(excluding projections)
Mass
Approx. 500 g (17.6 oz.)
Cord length
Approx. 1500 mm (59.06")
Appendix
Appendix 1 9613 REMOTE CONTROL BOX (SINGLE)
Two types of remote-control boxes are available: the 9613 for use with a single
hand and the 9614 for use with both hands. The 9613 REMOTE CONTROL BOX
(SINGLE) is equipped with a START key, a STOP key, and an OPERATE switch,
which turns ON/OFF the remote-control box. The STOP key remains lit as long as a
voltage is being output.
