227
Servicing
TURN OFF all the power switches.
(13) Mount the new compressor.
Attaching the nuts rst and then perform brazing according to the following order:
(a) Oil Discharge Pipe
(b) Discharge Pipe
(c) Suction Pipe
(d) Injection Pipe
NOTE:
1. When mounting the new compressor on the base, take special care not to contact the piping. If contacted, piping may
be deformed.
2. The new compressor should be mounted with the cap, and remove the cap just before starting the brazing work.
3. Connect the charging hose with the check joint at the low pressure side to release pressure.
4. When brazing the suction pipe, make sure that the connecting part is rmly inserted into the compressor and that the
piping root is cooled, in order to prevent the brazing material from entering the compressor.
Tool Burner, Wet Cloth, Pliers
To Next Page
