251
Servicing
TURN OFF all the power switches.
Tool Phillips Screwdriver, Long-Nose Pliers, Pliers
● AVWT-72~96FFFH
Front Side (For Main) The Interior of the Electrical Box (For Main)
PCB
Invert PCB1
Invert PCB1
NF1
DCL1
DCL1
● AVWT-120FFFH
Front Side (For Main)
The Interior of the Electrical Box (For Main)
Invert PCB1
PCB1
DCL1
FANM
FANM
Invert PCB1
NF2
DCL1
B
(Screw for Outdoor
Unit PCB Fixing Plate)
B
(Screw for Outdoor
Unit PCB Fixing Plate)
TB1
TB1
TB1
TB1
