252
Servicing
● AVWT-144~192FFFH
Front Side (For Main)
The Interior of the Electrical Box (For Main)
Invert PCB1
Invert PCB1
PCB
DCL1
DCL2
Invert PCB1
Invert PCB1
NF1
NF1
DCL1
DCL2
Item Part Name Item Part Name
PCB Outdoor Unit PCB Inverter PCB1/PCB2 Inverter PCB
FANM Fan Controller
DCL1, 2 Reactor
Noise Filter
TB1
Terminal Block
NF1,2
B
(Screw for Outdoor
Unit PCB Fixing Plate)
TB1
TB1
