19
General Data
Model：AVWT-144*, AVWT-1 68*
unit: in.(mm)
Maintenance panel
Electrical box
Connection of refrigerant gas pipe
Connection by welding
Connection of refrigerant gas pipe
Connection by welding
Connection of refrigerant liquid pipe
Connection with flare opening
Anchor bolt fixing hole
43/64(17)
28-17/64(718)
(Foundation bolt hole spacing)
Drain port (Φ1-1/32(26)×5)
Drain pipe connector
(optional)
8-11/32(212)
30-45/64(780)
4-9/64(105)
5-45/64(145)
10-7/16(265)
14-61/64(380)
8-47/64(222)
10-3/4(273)
6-39/64 (168)
25/32(20)
2-23/64(60)
12-43/64 (322)
9-29/64 (240)
7-13/64 (183)
24-7/32(615)
9-41/64
(245)
1-17/32(39)
26-17/64(667)
2-1/64(51)
2-43/64(68)
4×25/32(20)×19/32(15)
2-43/64(68)47-29/32(1217)
43/64(17)
10-15/32
(266)
28-31/32
(736)
5-63/64
(152)
6-3/16
(157)
10-33/64 (267)
4-1/16(103)
9-1/16(245)
4-7/8 (124)
To Next Page
