1. GETTING STARTED
1-9
Table 1-1 Function of Each Part (2/5)
Name Function
AC inlet Used for connecting a power cord.
Power supply A power supply module with a wide-range input voltage (100 to 240
VAC).
Audio port (LINE IN) An audio line input.
Audio port (LINE OUT) An audio line output.
Serial port (COM1)
(9 pins: RS-232C)
You can use this connector to connect a device such as a modem that uses
a serial interface.
(See “5.8.1 Connector specifications”.)
Serial port (COM2)
(9 pins: RS-232C)
(optional)
Connects a device such as a modem that uses a serial interface.
(See “5.8.1 Connector specifications”.)
RAS external contact port
(25 pins: EXT)
(optional)
A connector for connecting external contacts. (See “5.8.1 Connector
specifications”.)
DVI-I port (*1)
Connects the cable from the digital interface of a display. (See “5.8.1
Connector specifications”.)
DVI-D port Connects the cable from the digital interface of a display. (See “5.8.1
Connector specifications”.)
DisplayPort Connects the cable from the digital interface of a display. (See “5.8.1
Connector specifications”.)
PCI bus slot Used as a slot to insert a PCI board.
PCI Express x16 bus slot Used as a slot to insert a PCI Express x16 board.
PCI Express x4 bus slot Used as a slot to insert a PCI Express x4 board. But the connector is a PCI
Express x16 connector.
PCI Express x1 bus slot Used as a slot to insert a PCI Express x1 board.
USB port (USB2.0/USB3.0) Used to connect a device that uses a USB interface.
(*1) By using a conversion connector or DVI-A cable, you can output an analog VGA signal. The
conversion connector or DVI-A cable must be provided by the user.
