TRANSPORTING
6-4
Unloading
CAUTION: The rear end of the flatbed where it
meets the ramp is a sudden bump. Take care
when traveling over it.
IMPORTANT: Prevent possible damage to the front
attachment. Always position the arm at
90° to the boom when unloading the
machine. Unloading the machine with
the arm tucked in may cause machine
damage.
1. To move the machine over end of the trailer onto the
ramp, rest the flat surface of the bucket on the
ground. Angle of the arm to the boom should be 90
to 110°.
IMPORTANT: Prevent possible damage to the hydrau-
lic cylinders. Do not allow the machine
to hit the ground hard with the bucket.
2. The bucket must be on the ground before the ma-
chine begins to tip forward.
3. As the machine moves forward, raise the boom and
extend the arm until the machine is completely off the
ramp.
M1CC-05-010
M1CC-05-011
90 to 110
