OPERATOR'S STATION
1-24
Part Name
1- Front Vent
2- Foot Vent
3- Defroster Vent
4- Rear Vent
5- Control Panel
6- Blower Switch
7- Liquid Crystal Display (LCD)
8- Air Conditioner Switch
9- AUTO Switch
10- OFF Switch
11- Temperature Control Switch
12- Circulation Mode Switch
13- Fresh Air Mode Switch
14- MODE Switch
NOTE: Except for the foot vent, all vents are provided
with louvers to adjust the air flow direction. In
addition, the louvers on the front vent and de-
froster vent can be completely opened and
closed by hand.
