4-1
Correct operation will result in extending the service life of
each part and component as well as saving fuel and oil. Always
be sure to safely and efficiently operate the machine while
paying attention to the following points.
1. While checking the tires for abnormal air pressure and
any obvious damage, make sure that there is no hazard
-
ous and/or obstacles in and around the vicinity of the
machine.
2. After raising the lift arm set the machine to the driving
attitude, ground, fully tilt the bucket backward.
3. Before driving on public roads, set the machine to the
driving attitude as illustrated to the right. Be sure to place
front control lever lock (1) in the LOCK position (2) so that
the machine will not move even if the work tool control
levers are accidentally operated.
M4GB-04-001
M4GB-01-050
UNLOCK
LOCK
Driving Attitude
