7-108
10. Muffler mounting bolt
Model ZW310
Bolt dia. mm 12 12 16 16
Quantity
4 4 2 1
M4GB-07-133
11. Counterweight mounting bolt
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm
30 30 30 30
Quantity
4 4 4 4
M4GB-07-134
12. Top center pin upper flange lock
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm
16 16 16 16
Quantity
7 7 10 10
M4GB-07-135
