7-109
13. Bottom center pin lock
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm 16 16 16 16
Quantity
1 1 1 1
M4GB-07-136
14. Loader front pin lock
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm
12 16 16 16 16
Quantity
4 9 13 13 13
M4GB-07-137
15. Steering cylinder pin lock
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm
16 16 16 16
Quantity
4 4 4 4
M4GB-07-138
M4GB-07-006
