7-110
16. Radiator frame mounting bolt
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm 16 16 16 16
Quantity
6 6 6 6
M4GB-07-151
17. Radiator mounting bolt
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm
10 8 8 10
Quantity
2 4 4 4
M4GB-07-139
M4GB-07-140
18. Intercooler mounting bolt
Model ZW180 ZW220 ZW250 ZW310
Bolt dia. mm
10 10 10 12
Quantity
2 4 4 6
M4GB-07-142M4GB-07-141
ZW220, ZW250 ZW310
ZW220, ZW250 ZW310
M4GF-07-009
ZW180
M4GF-07-009
ZW180
