1-42
•
Temperature Control Switch (9)
Sets the air temperature in the range of 18 to 32.0 °C (65 to
90 °F) in the MANUAL and AUTO modes. Temperature can
be set by 0.5 °C (0.9 °F) increments. The set-temperature is
displayed on the LCD (8) center.
• Increasing Temperature
Each time the top side mark “ ” on temperature control
switch (9) is pressed, the set-temperature is increased by
0.5 °C (0.9 °F) increments.
• Decreasing Temperature
Each time the bottom side mark “
” on temperature con-
trol switch (9) is pressed, the set-temperature is decreased
by 0.5 °C (0.9 °F) increments.
•
Temperature Control Switch
Temperature Mode Change (Centigrade
↔
Fahrenheit)
Press both “
” and “ ” marks on the temperature control
switch for longer than 5 seconds at the same time to change
the temperature mode (Centigrade
↔
Fahrenheit). (Unit in
temperature mode is abbreviated.)
Temperature Mode Display on LCD
Centigrade 18.0 to 32.0
Fahrenheit 63 to 91
M178-01-017
