5. Configuration and Function of Internal Memory
5.5. PUT/GET function block use area (parameter area)
R200 Analog Input Module 2MLF-AV8A, AC8A User's Guide 101
September 2010 Honeywell
Average process setting
1. You can enable/disable average process per channel.
2. When disabling the average process, all channels are set as sampling process.
3. The following figure is an example for setting average process for channel 7.
B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
- - - - - - - - CH7 CH6 CH5 CH4 CH3 CH2 CH1 CH0
BIT Description
0 Disable
1 Enable
Average process method setting
1. In average process method, there are Count average, and Time average.
2. All channels execute average process by Count if Time/Count average process is
not set.
