CLSS Gateway - Installation and Users’ Manual | P/N:LS10248-000HW-E | REV. F | FEB/11/2022 118
Farenhyt Panels Connecting to the Panels
On the Panel Side
In the power board of the panel:
• Connect the Red wire to the +ve pin.
• Connect the Black wire to the -ve pin.
Figure C.10: Farenhyt Panel: RS-485 Connections
(Future)
*
(* For panel connection, use only the RS-485A port )
To Next Page
