Triga Panels Connecting to the Panels
C.13 Triga Panels
C.13.1 Connection Options
The gateway operates only with the Triga fire alarm control panels as listed in the table
below:
Table C.11: Triga Panel Connection Options
Minimum Required Versions
For the Panel: 6.05.01
For the CLSS Gateway: 3.1.4.74
C.13.2 To Use an RS-485 Connection
Using an RS-485 cable the CLSS Gateway connects with the annunciator primary
terminal of the panel.
1. On the Gateway Side
At the RS-485 A port in the gateway board:
• Connect the A connector to the IN+ pin of the RS-485 A port.
• Connect the B connector to the IN- pin of the same RS-485 A port.
The RS-485 ports in the gateway board are labeled as 3 and 4 in the Figure C.2.
2. On the Panel Side
At the S-BUS board in the ANN-BUS PRI terminal:
• Connect the RS-485 +ve wire to the A port.
• Connect the RS-485 -ve wire to the B port.
3. Power Connection
On the Gateway Side
In the power supply port (labeled 7 in the Figure C.2):
• Connect the Red wire to the +24V pin.
• Connect the Black wire to the Gnd pin.
On the Panel Side
In the power board of the panel:
• Connect the Red wire to the +ve pin.
• Connect the Black wire to the -ve pin.
Fire Alarm Panel Models RS-485 UART/TTL RS-232 USB
TR-75R Yes No No No
TR-75B Yes No No No
TR-2100R Yes No No No
TR-2100B Yes No No No
TR-R2100R Yes No No No
TR-R2100B Yes No No No
TR-2100ECSR Yes No No No
TR-2100ECSB Yes No No No
CAUTION: WHEN SUPPORTING THE ALARM TRANSMISSION, IT IS RECOMMENDED THAT THE TRIGA
PANEL SHOULD USE SECONDARY ANN BUS CHANNEL WITH CLASS A WIRING.
IF THE ALARM TRANSMISSION SERVICE IS NOT USED, THE PANEL CAN USE EITHER THE PRIMARY OR
THE SECONDARY ANN BUS CHANNEL FOR THE CLSS GATEWAY CONNECTION.
CAUTION: CONNECT EITHER THE CLSS GATEWAY OR THE ANN S/P G MODULE WITH THE PANEL. BOTH
OF THEM SHOULD NOT BE CONNECTED TOGETHER WITH THE PANEL.
