Register Mapping Modbus Communications
7.22.3 Point Device Type Input Registers
There are 6000 point device type holding registers. Each register address consists of two
bytes representing a detector or module.
405401 405700 L10D1–L10D300
405701 406000 L10M1–L10M300
Table 7.10: Point Status Holding Register Device/Module Addresses (Continued)
NOTE: On the AFP-2800, output activation status is not reported to the CLSS Gateway and
therefore the bits and event type will always indicate a non-active state.
NOTE: If the point is not present in the panel programming, all bits in the byte will contain
a value of 1 or FFFFH.
Table 7.11: Point Device Type Input Register Bit Definitions
Upper Byte Lower Byte
Bit
No.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Device Types (see 7.31 "Device Types")
Table 7.12: Input Register Addresses of the Point Device Types
Start
Address
End
Address
Address
300001 300300
L1D1–L1D300
300301 300600 L1M1–L1M300
300601 300900 L2D1–L2D300
300901 301200 L2M1–L2M300
301201 301500 L3D1–L3D300
301501 301800 L3M1–L3M300
301801 302100 L4D1–L4D300
302101 302400 L4M1–L4M300
302401 302700 L5D1–L5D300
302701 303000 L5M1–L5M300
303001 303300 L6D1–L6D300
303301 303600 L6M1–L6M300
303601 303900 L7D1–L7D300
303901 304200 L7M1–L7M300
304201 304500 L8D1–L8D300
304501 304800 L8M1–L8M300
304801 305100 L9D1–L9D300
305101 305400 L9M1–L9M300
305401 305700 L10D1–L10D300
305701 306000 L10M1–L10M300
