System Troubles Register Map Modbus Communications
7.32 System Troubles Register Map
Feedback Tracking 00A1H Auxiliary 1060H
Hydrant 00A2H Door Holder 1061H
Control 1000H AAM Sounder 1062H
Wireless Control 1001H TYPE 5 Control 1063H
Table 7.33: System Troubles Register Map
Register
Bit
No.
System Trouble Name
Bit
No.
System Trouble Name
460001
0
GROUND FAULT
8
INTERNAL RAM ERROR
1
AC FAIL
9
EXTERNAL RAM ERROR
2
BATTERY
10
PROGRAM CORRUPTED
3
STYLE 6 POS. LOOP 1
11
NO DEV. INST ON L1
4
STYLE 6 POS. LOOP 2
12
PANEL DOOR OPEN
5
CORRUPT LOGIC EQUAT
13
AUXILIARY TROUBLE
6
LCD80 SUPERVISORY
14
TERM. SUPERVISORY
7
EPROM ERROR / FLASH IMAGE
ERROR
15
ANNUN. 1 TROUBLE
460002
0
ANNUN. 1 NO ANSWER
8
ANNUN. 5 NO ANSWER
1
ANNUN. 2 TROUBLE
9
ANNUN. 6 TROUBLE
2
ANNUN. 2 NO ANSWER
10
ANNUN. 6 NO ANSWER
3
ANNUN. 3 TROUBLE
11
ANNUN. 7 TROUBLE
4
ANNUN. 3 NO ANSWER
12
ANNUN. 7 NO ANSWER
5
ANNUN. 4 TROUBLE
13
ANNUN. 8 TROUBLE
6
ANNUN. 4 NO ANSWER
14
ANNUN. 8 NO ANSWER
7
ANNUN. 5 TROUBLE
15
ANNUN. 9 TROUBLE
460003
0
ANNUN. 9 NO ANSWER
8
ANNUN.13 NO ANSWER
1
ANNUN.10 TROUBLE
9
ANNUN.14 TROUBLE
2
ANNUN.10 NO ANSWER
10
ANNUN.14 NO ANSWER
3
ANNUN.11 TROUBLE
11
ANNUN.15 TROUBLE
4
ANNUN.11 NO ANSWER
12
ANNUN.15 NO ANSWER
5
ANNUN.12 TROUBLE
13
ANNUN.16 TROUBLE
6
ANNUN.12 NO ANSWER
14
ANNUN.16 NO ANSWER
7
ANNUN.13 TROUBLE
15
ANNUN.17 TROUBLE
