Load Capacity
• 90 lb per zone for speeds up to 180 fpm (Itoh only)
• 35 lb per zone for speeds up to 300 fpm
• Additional capacity available upon request
Minimum Product
Sizes
• 9 in. x 12 in. for right angle transfer
• 6 in. x 9 in. for 3-inch centers, wheel divert, and RT3
• 4 in. x 6 in. for 2-inch centers (no diverts or transfers)
Refer to the T-Bone Merge Feeder Guidelines and Merge Guidelines
sections for minimum height requirements.
If transfers feed only to belted sections or chutes, and product is aligned to
the inside radius of curved sections, minimum length is 9 in. and minimum
width is 6 in.
Maximum Product
Sizes
Length:
• 19 in. for 24 in. zone length
• 24 in. for 30 in. zone length
• 30 in. for 36 in. zone length
• 42 in. for 48 in. zone length
Width:
• 14 in. for 16 in. between the frames (BF)
• 20 in. for 22 in. BF
• 26 in. for 28 in. BF
• 32 in. for 34 in. BF
• 38 in. for 40 in. BF
The size capacity of curves must be calculated. Merge and divert sections
might require special consideration. Contact
the Product Manager for the
current rate calculation tools.
Product Types
Corrugated cartons and plastic totes
Drive Rollers
• 1.9 in. diameter (ABEC-1 bearing)
• 24 VDC brushless motor
• 7/16 in. hex axle
• 12 in. cable length
Drive Roller Weight
and Speeds
• 70 lb per zone, up to 180 fpm for Standard Torque Standard Speed
(STSS) and Standard Torque Standard Speed with Brake (STSSB)
drive rollers
• 90 lb per zone, up to 180 fpm for High Torque Standard Speed
(FP55) drive roller
• 35 lb per zone, up to 300 fpm for High Torque High Speed (HTHS)
drive roller
Axle Locks
• Intelligrated 49105100 or 49107500
• One per roller required for the STSS and STSSB rollers, located on
cable side
• Two required for the HTSS and HTHS rollers located on each side of
the frame (Itoh only).
Control Card
CS1001 or HB510
To Next Page
