Honeywell MDR 710 - 5.28 ASRS P&D Inbound and Outbound

MDR 710 – WWL Conveyor | Maintenance Manual | 29349817 93
November 16, 2020
Spare Parts
SEQ QTY PART NO Description
10 1 49023000 MDR 710-SCAN BED PE BRACKET 18MM ROUND
12 1 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
13 3 49060400 MDR 710 REFL BRACKET ASSY
14 2 49106100 MDR 710 PE PHANTOM ASSY SICK ZL1 CS1001
15 1 491140__ WWL ST-60-180FPM NGR STD TRQ RLLR __BF 15"CABLE WITH
TRACKING TIRE AND AXLE LOCK
491140__ WWL HT-60-180FPM NGR HIGH TRQ RLLR __BF 15"CABLE
WITH TRACKING TIRE AND AXLE LOCK
491078__ WWL ST-60-180FPM NGR STD TRQ RLLR __BF 15"CABLE WITH
TRACKING TIRE
491102__ WWL HT-60-180FPM NGR HIGH TRQ RLLR __BF 15"CABLE
WITH TRACKING TIRE
20 4 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
21 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
22 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
23 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
25 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O VERSION
E0 OR GREATER B&R #X67UM4389
26 1 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ ALARM OUTPUT PNP SICK #1051589 (MODEL #ZL2-
F2400S07)
27 1 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-
4100B) REPLACES 44009600
28 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
29 1 15013100 MDR MTG BKT POINTS UP TOP-BTM PLT WWL#FFXSTL006-00
30 1 15013200 MDR MTG BKT POINTS UP MIDDLE PLT WWL#FFXSTL005-00
31 1 49048624 MDR 710 BELT FLEXAM EM 8/2 0+P8 BLUE AS 5"W 24"ZN
32 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
5.28 ASRS P&D Inbound and Outbound
P&D conveyor consists of 1 or 2 zones of full-width belt MDR conveyor and 1 zone of
roller MDR conveyor.
