90 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
Spare Parts
5.26 Belt Strip Dense Decline Assy Roller Low 24"
Zone 24" Lg with Field Kit (491245)
Figure 5-18 Belt Strip Dense Decline Assy Roller Low 24" Zone 24" Lg with Field Kit
Table 5-18 Belt Strip Dense Decline Assy Roller Low 24" Zone 24" Lg with Field Kit Spare Parts
SEQ QTY PART NO Description
1 2 490597024 MDR 710-STRT RLR LOW RAIL 24" LG
2 2 490388__ 710 MDR EXTRUDED WIREWAY X-OVER __BF
3 2 490000__ MDR SPDR STAMPED __"BF
6 2 20054600 GROMMET 1.125"OD X .625"ID FOR .875 DIA HOLE
8 2 150004__ WWL ST 60-180FPM NO GRV STD TRQ BRK RLLR __BF (15 IN
CABLE)
