MDR 710 – WWL Conveyor | Maintenance Manual | 29349817 91
November 16, 2020
SEQ QTY PART NO Description
491078__ 710 MDR WWL STSS W/ BRK DENS PAT BELT RLR WITH
TRACKING TIRE W__
9 3 490382__ 710 MDR BELT ZN SLIDER PAN __"BF
12 1 49091900 REFLECTOR MICROCUBE SICK #7123377
13 1 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589 (MODEL ZL2-
F2400S07)
14 2 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
15 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O
VERSION E0 OR GREATER B&R #X67UM4389
49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
19 2 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
20 2 49105100 WWL POINTS UP 3 PLT AXLE LOCK
21 6 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK
5.594LG 83A
22 3 49048624 MDR 710 BELT FLEXAM EM 8/2 0+P8 BLUE AS 5"W 24"ZN
23 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
24 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
25 1 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-
4100B) REPLACES 44009600
To Next Page
