58 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
Spare Parts
SEQ QTY PART NO Description
6 1 49447900 MDR 710 PE BRACKET PHANTOM ASSY
49447800 MDR 710 PE BRACKET PHANTOM ASSY
25528500 MDR 710 PE BRACKET PHANTOM ASSY
25528800 MDR 710 PE BRACKET PHANTOM ASSY
7 2 49042700 MDR 710 FRAME GROUNDING FLAT
8 1 490____ 710 MDR CONTROL CARD PHANTOM ASSY
5.10 Straight Roller High 24" Zone 72" Lg (493019)
Figure 5-2 Straight Roller High 24" Zone 72" Lg
Table 5-2 Straight Roller High 24" Zone 72" Lg Spare Parts
SEQ QTY PART NO Description
1 2 490601072 710 MDR-STRT RLR HIGH RAIL 72" LG
2 21 29416300 O-BELT 3/16" DIA X 9.438" CUT LENGTH 83A DURO STATIC
DISSIPATIVE BLACK (3"CTR)
