MDR 710 – WWL Conveyor | Maintenance Manual | 29349817 59
November 16, 2020
SEQ QTY PART NO Description
29437700 O-BELT 3/16" DIA X 11.25" CUT LENGTH 85A DURO STATIC
DISSIPATIVE BLACK
29850300 O-BELT 3/16" DIA X 9.093" CUT LENGTH 88A DURO HIGH
TENSION TRANSPARENT BLUE (3" CTRS)
29850500 O-BELT 3/16" DIA X 10.7" CUT LENGTH 88A DURO HIGH
TENSION TRANSPARENT BLUE (4" CTRS)
3 21 140066__ ROL G196AB __.00"BF MDR DGR AX7 B2006
7 4 490000__ MDR SPDR STAMPED __"BF
8 3 20054600 GROMMET 1"OD X .71"ID FOR .87 DIA HOLE
9 3 49105100 WWL POINTS UP 3 PLT AXLE LOCK
10 3 150005__ WWL HT 60-180FPM DGR HI TRQ RLLR __BF (15 IN CABLE)
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
150001__ WWL ST 60-180FPM DGR STD TRQ RLLR __BF (15 IN CABLE)
11 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
13 3 49060801 MDR 710 HI RLR PE BRKT BUYOUT
14 3 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589
(MODEL ZL2-F2400S07)
17 3 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
19 2 49042700 MDR 710 FRAME GROUNDING FLAT
20 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O VERSION
E0 OR GREATER B&R #X67UM4389
21 1 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.3
22 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
23 1 49109800 MDR 710 WTR PE 4 PIN W/ BRKT CS1001
24 1 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-4100B)
REPLACES 44009600
To Next Page
