MDR 710 – WWL Conveyor | Maintenance Manual | 29349817 89
November 16, 2020
Spare Parts
SEQ QTY PART NO Description
29 12 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK 5.594LG
83A
30 6 49048624 MDR 710 BELT FLEXAM EM 8/2 0+P8 BLUE AS 5"W 24"ZN
31 1 150007__ WWL HT 60-180FPM NO GRV HI TRQ RLLR __BF (15 IN CABLE)
150004__ WWL ST 60-180FPM NO GRV STD TRQ BRK RLLR __BF (15 IN
CABLE)
491102__ WWL HT-60-180FPM NGR HIGH TRQ RLLR __BF 15"CABLE WITH
TRACKING TIRE
491078__ WWL ST-60-180FPM NGR STD TRQ RLLR __BF 15"CABLE WITH
TRACKING TIRE
491078__ 710 MDR WWL STSS W/ BRK DENS PAT BELT RLR WITH
TRACKING TIRE W__
491079__ 710 MDR G196AB MDR DGR DENSE PATT BELT WITH
TRACKING TIRE AND ADH W__
491142__ 710 MDR G196AB MDR DGR DENSE PATT BELT WITH
TRACKING TIRE W__
32 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
33 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
35 1 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-4100B)
REPLACES 44009600
