66 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
Spare Parts
SEQ QTY PART NO Description
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
10 1 140044__ ROL G196AB-__.00"BF DGR MDR AX7
140066__ ROL G196AB __.00"BF MDR DGR AX7 B2006
11 8 140002__ ROL G196AB __.00"BF AX7
140061__ ROL G196AB __.00BF AX7 B2006
12 2 140159__ ROLL G196AB-__W FGR 2EAEND AX7 1WAY
140159400 ROL G196AB-40W 2- GRVS EA END 1 WAY CLT—SST
# R34.019NP111H3EEEE
491076__ RLLR G196 NO GROOVE __BF WITH TRACKING TIRE
491103__ 710 MDR G196AB MDR DGR STRIP BELT WITH TRACKING TIRE
W__
491141__ 710 MDR G196AB MDR DGR STRIP BELT WITH TRACKING TIRE
AND ADH W__
13 6 305227 O-BELT .25 X 9.437 LG 83A
14 12 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK 5.594LG
83A
15 6 490223__ 710 MDR STRIP BELT __" ZN
16 2 49091900 REFLECTOR MICROCUBE SICK #7123377
17 2 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589 (MODEL ZL2-F2400S07)
18 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
19 3 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
22 2 49059000 MDR 710 PIVOT PF BRACKET DOWNSTREAM
23 2 49059100 MDR 710 PIVOT PF BRACKET UPSTREAM
26 2 49042700 MDR 710 FRAME GROUNDING STRAP
27 2 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
28 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
29 2 15013100 MDR MTG BKT POINTS UP TOP-BTM PLT WWL#FFXSTL006-00
30 3 15013200 MDR MTG BKT POINTS UP MIDDLE PLT WWL #FFXSTL005-00
31 4 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O VERSION
E0 OR GREATER B&R #X67UM4389
32 5 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-4100B)
REPLACES 44009600
33 6 44003200 FUSE 3 AMP ATC VIOLET ATC-3
34 7 49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
