68 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
SEQ QTY PART NO Description
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
491076__ RLLR G196 NO GROOVE __BF WITH TRACKING TIRE
9 12 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK 5.594LG
83A
10 6 490223__ 710 MDR STRIP BELT __" ZN
11 1 490388 710 MDR EXTRUDED WIREWAY X-OVER __BF
12 4 20054600 GROMMET 1"OD X .71"ID FOR .87 DIA HOLE
13 4 490000 MDR SPDR STAMPED __"BF
16 2 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589
(MODEL ZL2-F2400S07)
17 2 49091900 REFLECTOR MICROCUBE SICK #7123377
18 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
19 3 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
22 2 49058900 710 MDR PIVOT NO BRACKET DOWNSTREAM
23 2 49103000 710 MDR PIVOT NO BRACKET UPSTREAM
27 2 49042700 MDR 710 FRAME GROUNDING STRAP
28 2 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
31 2 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
32 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
33 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O VERSION
E0 OR GREATER B&R #X67UM4389
34 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
35 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
36 1 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-4100B)
REPLACES 44009600
