70 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
SEQ QTY PART NO Description
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
491103__ 710 MDR ROL ST TORQ __W 2- GRVS EA END 1 WAY CLT
WITH TRACKING TIRE
140159__ ROL G196AB-__W 2- GRVS EA END 1 WAY CLT- SS
# R__.019NP111H3EEEE
10 6 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK
5.594LONG 83A
11 4 305227 O-BELT .25 X 9.437 LG 83A
12 3 490223__ 710 MDR STRIP BELT __" ZN
13 1 49037600 710 MDR BnR MODULE W/BRKT
14 1 49091900 REFLECTOR MICROCUBE SICK #7123377
15 1 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589
(MODEL ZL2-
F2400S07)
16 2 29042700 LABEL CEMA #CHR930004 SHORT (1.75 X 5.00)
17 2 29003000 LABEL PRODUCT TRAVEL
18 2 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
19 2 49042700 MDR 710 FRAME GROUNDING STRAP
20 4 20061200 BOLT HEX FLG .313-18 X .750 THREAD CUTTING
21 4 20061500 BOLT HEX FLG .313-18 X .750
22 1 15013100 MDR MTG BKT POINTS UP TOP-BTM PLT WWL#FFXSTL006-00
23 1 15013200 MDR MTG BKT POINTS UP MIDDLE PLT WWL#FFXSTL005-00
24 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O
VERSION E0 OR GREATER B&R #X67UM4389
25 1 23278100 PHOTO EYE W/ 3-PIN WAGO CONNECTOR ZL1 PNP DARK
OPERATE SICK #1044597 (MODEL #ZL1-F2460S03)
26 1 23295400 HB-510P-IT7 PNP MDR HIGH TORQUE CONTROL CARD ZPA
ITOH DENKI (WAS HB510P-IT3, 4, 5 & 6)
27 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
28 1 49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
29 1 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-
4100B) REPLACES 44009600
To Next Page
