72 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
SEQ QTY PART NO Description
8 1 150003__ WWL ST 60-180FPM NO GRV STD TRQ RLLR __BF (15 IN
CABLE)
150007__ WWL HT 60-180FPM NO GRV HI TRQ RLLR __BF (15 IN CABLE)
9 3 150001__ WWL ST 60-180FPM DGR STD TRQ RLLR __BF (15 IN CABLE)
150005__ WWL HT 60-180FPM DGR HI TRQ RLLR __BF (15 IN CABLE)
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
491142__ 710 MDR G196AB MDR DGR DENSE PATT BELT WITH
TRACKING TIRE W__
491079__ 710 MDR G196AB MDR DGR DENSE PATT BELT WITH
TRACKING TIRE AND ADH W__
10 1 140066__ ROL G196AB __.00"BF MDR DGR AX7 B2006
11 7 140061__ ROL G196AB __.00BF AX7 B2006
12 2 140159__ ROL G196AB-__W 2- GRVS EA END 1 WAY CLT
13 2 49091900 REFLECTOR MICROCUBE SICK #7123377
14 2 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589
(MODEL ZL2-F2400S07)
15 4 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
16 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
19 2 49059000 MDR 710 PIVOT PF BRACKET DOWNSTREAM
20 2 49059100 MDR 710 PIVOT PF BRACKET UPSTREAM
23 4 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
25 4 49105100 WWL POINTS UP 3 PLT AXLE LOCK
26 6 305227 O-BELT .25 X 9.437 LG 83A
27 12 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK 5.594LG
83A
28 6 49048624 MDR 710 BELT FLEXAM EM 8/2 0+P8 BLUE AS 5"W 24"ZN
29 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O VERSION
E0 OR GREATER B&R #X67UM4389
30 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
