74 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
SEQ QTY. PART NO Description
2 3 150004__ WWL ST 60-180FPM NO GRV STD TRQ BRK RLLR __BF (15 IN
CABLE)
150001__ WWL ST 60-180FPM DGR STD TRQ RLLR __BF (15 IN CABLE)
150005__ WWL HT 60-180FPM DGR HI TRQ RLLR __BF (15 IN CABLE)
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
491142__ 710 MDR G196AB MDR DGR DENSE PATT BELT WITH
TRACKING TIRE W__
491079__ 710 MDR G196AB MDR DGR DENSE PATT BELT WITH
TRACKING TIRE AND ADH W__
3 7 140061__ ROL G196AB __.00BF AX7 B2006
4 3 140159__ ROL G196AB-__W 2- GRVS EA END 1 WAY CLT
5 6 305227 O-BELT .25 X 9.437 LG 83A
6 1 150003__ WWL ST 60-180FPM NO GRV STD TRQ RLLR __BF (15 IN
CABLE)
150007__ WWL HT 60-180FPM NO GRV HI TRQ RLLR __BF (15 IN CABLE)
7 2 490388__ 710 MDR EXTRUDED WIREWAY X-OVER __BF
8 4 20054600 GROMMET 1.125"OD X .625"ID FOR .875 DIA HOLE
9 4 490000__ MDR SPDR STAMPED __"BF
12 2 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589
(MODEL ZL2-F2400S07)
13 2 49091900 REFLECTOR MICROCUBE SICK #7123377
14 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
15 4 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
18 2 49058900 710 MDR PIVOT NO BRACKET DOWNSTREAM
19 2 49103000 710 MDR PIVOT NO BRACKET UPSTREAM
23 2 49042700 MDR 710 FRAME GROUNDING STRAP
24 4 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
27 4 49105100 WWL POINTS UP 3 PLT AXLE LOCK
28 12 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK 5.594LG
83A
29 6 49048624 MDR 710 BELT FLEXAM EM 8/2 0+P8 BLUE AS 5"W 24"ZN
30 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-4100B)
REPLACES 44009600
31 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O VERSION
E0 OR GREATER B&R #X67UM4389
32 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
To Next Page
