76 MDR 710 – WWL Conveyor | Maintenance Manual | 29349817
November 16, 2020
SEQ QTY. PART NO Description
5 2 490388__ 710 MDR EXTRUDED WIREWAY X-OVER __BF
6 4 20054600 GROMMET 1.125"OD X .625"ID FOR .875 DIA HOLE
7 3 140061__ ROL G196AB __.00BF AX7 B2006
8 2 150001__ WWL ST 60-180FPM DGR STD TRQ RLLR __BF (15 IN CABLE)
150005__ WWL HT 60-180FPM DGR HI TRQ RLLR __BF (15 IN CABLE)
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
9 2 150007__ WWL HT 60-180FPM NO GRV HI TRQ RLLR __BF (15 IN CABLE)
10 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
PHANTOM ASSY WITH CABLES
49019200 710 MDR ELEC HB510 POWER CABLE 8"LG
11 1 49091900 REFLECTOR MICROCUBE SICK #7123377
12 1 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589 (MODEL ZL2-
F2400S07)
15 2 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
17 2 49042700 MDR 710 FRAME GROUNDING STRAP
20 2 49105100 WWL POINTS UP 3 PLT AXLE LOCK
21 4 305227 O-BELT .25 X 9.437 LG 83A
22 6 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK 5.594LG
83A
23 3 49048624 MDR 710 BELT FLEXAM EM 8/2 0+P8 BLUE AS 5"W 24"ZN
24 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
25 1 15013100 MDR MTG BKT POINTS UP TOP-BTM PLT WWL#FFXSTL006-00
26 1 15013200 MDR MTG BKT POINTS UP MIDDLE PLT WWL#FFXSTL005-00
27 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O VERSION
E0 OR GREATER B&R #X67UM4389
28 1 44003200 FUSE 3 AMP ATC VIOLET ATC-3
29 1 20046000 RIVET NYLON SNAP-LOCK .295-.335 GRIP (RICHCO# SR-
4100B) REPLACES 44009600
To Next Page
