MDR 710 – WWL Conveyor | Maintenance Manual | 29349817 81
November 16, 2020
SEQ QTY PART NO Description
150009160 WWL HT 100-300FPM DGR HI TRQ HI SPD RLLR 16BF (15 IN
CABLE)
150002__ WWL ST 60-180FPM DGR STD TRQ BRK RLLR __BF (15 IN
CABLE)
491076__ RLLR G196 NO GROOVE __BF WITH TRACKING TIRE
491103__ 710 MDR G196AB MDR DGR STRIP BELT WITH TRACKING
TIRE W__
491141__ 710 MDR G196AB MDR DGR STRIP BELT WITH TRACKING
TIRE AND ADH W__
13 1 150003__ WWL ST 60-180FPM NO GRV STD TRQ RLLR __BF (15 IN
CABLE)
150003555 WWL ST 60-180FPM NO GRV STD TRQ RLLR
55.71(1415MM)BF (15 IN CABLE)
150004__ WWL ST 60-180FPM NO GRV STD TRQ BRK RLLR __BF (15 IN
CABLE)
14 1 150004__ WWL ST 60-180FPM NO GRV STD TRQ BRK RLLR __BF (15 IN
CABLE)
491076__ 710 MDR WWL STSS W/ BRK STRIP BELT RLR WITH
TRACKING TIRE W__
15 12 29406800 TIRE URETHANE TRACKING 1.9RLR 1.00"WD 1/16"THK
5.594LG 83A
16 6 490223__ 710 MDR STRIP BELT __" ZN
17 2 49091900 REFLECTOR MICROCUBE SICK #7123377
18 2 23386800 PHOTO EYE 4-PIN WAGO CONNECTOR PNP DARK ACTUATE
W/ALARM OUTPUT PNP SICK #1051589 (MODEL ZL2-
F2400S07)
19 2 23325800 WWL CS1001 SZC CONTROL CARD #CS10010200 VERSION
1.2D7.2
20 1 49037600 710 MDR BnR MODULE W/BRKT
24 2 490382 710 MDR BELT ZN SLIDER PAN __"BF
27 2 49058900 710 MDR PIVOT NO BRACKET DOWNSTREAM
28 2 49103000 710 MDR PIVOT NO BRACKET UPSTREAM
30 4 305227 O-BELT .25 X 9.437 LG 83A
31 2 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
34 2 49042900 MDR 710 GROUND STRAP .5 X 12"LG W/.3125 TERM.
35 2 49042700 MDR 710 FRAME GROUNDING STRAP
36 1 165476 PUSH MOUNT CLIP PANDUIT #HCMP06C-12-M20
37 1 23276600 IDEAL MODULE FOR MDR710 UNIVERSAL MIXED I/O
VERSION E0 OR GREATER B&R #X67UM4389
38 1 49037600 710 MDR ELEC B&R INTELLIGRATED IDEAL MODULE
