NCA-2 Manual — P/N 52482:M5 03/20/2019 95
Appendix F: UL 8th Edition Panel Applications
The NCA-2 is compatible with the FACPs in this appendix that have software as described in Table F.1. Display differences and pro-
gramming requirements are noted in each section.
Use of the NCA-2 with these FACPs is subject to AHJ approval. Refer to “UL 864 Compliance” on page 8.
F.1 Conversions Common to UL 8th Edition Panels
Device Trouble Types
Device trouble types for the AFP-200, AFP-300/400,and AM2020/AFP-1010 FACPs will be displayed on the NCA-2 as follows:
Detector Sensitivity
NCA-2 screens that display detector sensitivity translate the AFP-200, AFP-300/400, and AM2020/AFP-1010FACP levels as follows:
F.2 AM2020/AFP-1010
Device Point Types
The device types for this panel will display according to the NCA-2 in Table F.4.
FACP Compatible with NCA-2 at Software Level:
AFP-200 Rev. 3.02 or greater
AFP-300, AFP-400 Rev. 3.65 or greater
AM2020, AFP-1010 SIB, DIA, CPU Rev. 4.0 or greater
Table F.1 Software Compatibility
FACP Device Trouble NCA-2 Displays:
Invalid Reply No Response
Low Chamber Value < 20% of alarm level Low Threshold
Maintenance required > 80% of alarm level Maintenance Alert
Sensitivity High Maintenance Alert
Sensitivity Low Maintenance Alert
Open Circuit Open Circuit
Short Circuit Short Circuit
Point Trouble General Trouble
Detector Failed Chamber Test Detector Failed Test
Drift Compensation Error Maintenance Alert
Verification Count Overflow Verify Count Over 20
Security Tamper Security Tamper
Security Invalid Reply No Response
Table F.2 NCA-2 Device Trouble Display
FACP Sensitivity Level NCA-2 Displays Sensitivity Level:
Low Sensitivity 9
Medium Sensitivity 5
High Sensitivity 1
Table F.3 NCA-2 Detector Sensitivity Display
AFP-1010/AM2020
Device Point Type
NCA-2 Displays:
AFP-1010/AM2020
Device Point Type
NCA-2 Displays:
HEAT(ANALOG) HEAT TROUBLE GEN TROUBLE
FIXED THER D HEAT(FIXED) TROUBLE FORC GEN TROUBLE
MON NORM CLD NC MONITOR FIXED PHOT D SMOKE(PHOTO)
SPRNKLR MNTR SPRINKLER SYS PAGE TELE PAGE
FORM C RELAY RELAY MON PULL STA PULL STATION
POWER(CONV) CONTROL MONITOR PAGE TELE PAGE
Table F.4 NCA-2 Display for AM2020/AFP-1010 Device Point Types
