NCA-2 Manual — P/N 52482:M5 03/20/2019 85
Point Program Menu Programming
5.6.3 Annunciator Board Label
When ACS BOARD is selected from the Point Program Menu, the ACS Label Menu appears.
Figure 5.46 ACS Label Menu Screen (1)
Soft Keys
ACS LABEL: Type a label for the selected annunciator. The label can have up to 40 characters.
TROUBLE REPORTING DELAY: Smoke Control Systems only: Adjustable trouble timer for FSCS. Programmable range is 0 to 180
seconds. Default: 90
PAIRING: Smoke Control Systems only: Select group 1, 2 or 3 to pair up to eight (8) FSCS boards so that multiple smoke control
modules can act as a single unit. If enabled, each FSCS address can only be assigned to one group and each group can be assigned up to
eight (8) FSCS addresses, Default: X
PAIRED FSCS: Smoke Control Systems only: Displays any FSCS boards that have been paired to this annunciator.
ACCEPT: Press to insert the logic function into the equation where the cursor is blinking, and to return to the previous screen.
Press the MORE softkey to display the second ACS label screen.
Figure 5.47 ACS Label Menu Screen (2)
Soft Keys
ZONE SELECTION: Press to assign the zone label that is to be displayed for the switch group selected.
VIEW: Press to view the associated zone label for the switch group selected.
UP/DOWN: Press to move between switch group selections.
ACS BOARD PROGRAMMING
A01
ACS LABEL:
EAST WING SPEAKERS
TROUBLE REPORTING DELAY: 90
PAIRING: X MORE
PAIRED FSCS: NONE ACCEPT
BACK
NOTE: This value may not exceed 90 seconds for ULC installations.
ACS BOARD PROGRAMMING
A01
<-ZONE SELECTION UP
SG1
SG2 DOWN
SG3
SG4
SG5 MORE
SG6
SG7
SG8 ACCEPT
VIEW BACK
