NCA-2 Manual — P/N 52482:M5 03/20/2019 97
AFP-200 UL 8th Edition Panel Applications
System Troubles
There is one FACP System Trouble that displays differently at the NCA-2.
Read Status
Read Status of Special Function Zone 7 on the AFP-300/AFP-400 is not supported.
Disable/Enable
Disable/Enable of zones on an AFP-300/AFP-400 is not supported.
Control ON/OFF
Control ON/OFF on the AFP-300/AFP-400 is not supported.
Shadow Points
Shadow points are not supported on an AFP-300/AFP-400.
MONITOR and CONTROL ACS points can not look at output modules, bell circuits or panel circuits on an AFP-300/AFP-400.
Auto-Acknowledge
A Network Adaptor Module (NAM) connected to an AFP-300/AFP-400 will auto-acknowledge an event on the panel. The panel then
shows the event as acknowledged, and this event can not be acknowledged again at the panel since it has already been acknowledged
locally. The NCA-2 or another display node must be used for acknowledgement.
F.4 AFP-200
The device types for this panel will display on the NCA-2 as follows:
System Troubles
There are two FACP System Troubles that display differently at the NCA-2.
Read Status
Read Status is not supported on the AFP-200.
Disable/Enable
Disable/Enable on an AFP-200 is not supported.
Control ON/OFF
SILENCE SIL SWITCH
SYSTEM RESET RESET SWITCH
EVACUATE EVACUATE SW
BURGLAR ALA SECURITY L
COMB.MONITOR SMOKE(MULTI)
AFP-300/AFP-400
System Trouble
NCA-2 Displays:
PROG. MODE ENTERED PROG MODE ACTIVATED
Table F.7 NCA-2 Display for AFP-300/AFP-400 System Trouble
AFP-300/AFP-400
Device Point Type
NCA-2 Displays:
Table F.6 NCA-2 Display for AFP-300/AFP-400 Device Point Types
AFP-200 Device Point
Type
Displayed at NCA-2 as
Device Point Type:
HEAT(ANALOG) HEAT
BURGLAR ALA SECURITY L
SUPERVISORY TRACK SUPERV
SILENCE SIL SWITCH
SYSTEM RESET RESET SWITCH
EVACUATE EVACUATE SW
Table F.8 NCA-2 Display for AFP-200 Device Point Types
AFP-200
System Troubles
Displayed at NCA-2 as:
NO DEVICES INSTALLED NO DEV.INST ON L1
PROG. MODE ENTERED PROG MODE ACTIVATED
Table F.9 NCA-2 Display for AFP-200 System Troubles
