96 NCA-2 Manual — P/N 52482:M5 03/20/2019
UL 8th Edition Panel Applications AFP-300/AFP-400
Annunciator Point Types
The annunciator types for this panel will display according to the NCA-2 Column in Table F.5.
.
F.3 AFP-300/AFP-400
Device Point Types
The device types for this panel will display on the NCA-2 as follows:
TRBLES PEND TROUBLE PEND ION DUCT DET SMOKE(DUCT I)
TRBL MONITOR TROUBLE MON NON ALARM NON FIRE
CMX CONTROL CONTROL FORMC MANUAL RELAY
CMX FORM C FORM C RESET SYSTEM MONTR SYS MONITOR
NON ALM MON NON FIRE DACT CONNECT GEN TROUBLE
GN ALARM EVC GEN ALARM SPRVSRY MNTR TRACK SUPERV
GN ALARM GEN ALARM SMOKE ION HP SMOKE(DUCT I)
GN ALARM FORC GEN ALARM SMOKE ION LP SMOKE(DUCT I)
GN WATER FLW GEN ALARM SMOKE(COMBO) SMOKE(MULTI)
GN TRBL FORC GEN TROUBLE SMOKE(PHOTV) SMOKE(PHOTO)
GN WAT FORC GEN ALARM SMOKE(IONV) SMOKE(ION)
GN SUPR FORC GEN SUPERVIS
CAUTION:
When using the NCA-2 to annunciate points on the AM2020/AFP-1010 over the network, enable state reporting in the
AM2020/AFP-1010 panel for control module points and “NONA”NOA” module points. Otherwise, any changes in the state of
these points on the FACP will not be annunciated over the network to annunciator points mapped to the NCA-2.
1. Choose option “I=PSYS” from the FACP programming menu for partial system programming.
2. Choose option “6=EXTEQ”.
3. Answer YES to the following questions:
• DO YOU WANT TO CHANGE THE CONTROL MODULE STATE REPORTING?
• DO YOU WANT TO REPORT CONTROL MODULE STATE CHANGES?
• DO YOU WANT TO CHANGE THE “NONA”/”NOA” MDULE STATE REPORTING?
• DO YOU WANT TO REPORT “NONA”/”NOA” MODULE STATE CHANGES?
OR, if completely programming the panel:
1. Choose option “2-FSYS”.
2. Answer YES to the following questions:
• DO YOU WANT TO REPORT CONTROL MODULE STATE CHANGES?
• DO YOU WANT TO REPORT “NONA”/”NOA” MODULE STATE CHANGES?
AFP-1010/AM2020
Annunciator Point Type
NCA-2 Displays:
AFP-1010/AM2020
Annunciator Point Type
NCA-2 Displays:
AMAN MANUAL AMON MONITOR
AAST ACKNOWLEDGE AINP MONITOR
ASGS SILENCE ACON CONTROL
ARES RESET ATEL TELEPHONE
ALMP NONE ASUP MONITOR
AZON MONITOR AFCM CONTROL
ADET MONITOR
Table F.5 NCA-2 Display for AM2020/AFP-1010 Annunciator Point Types
AFP-1010/AM2020
Device Point Type
NCA-2 Displays:
AFP-1010/AM2020
Device Point Type
NCA-2 Displays:
Table F.4 NCA-2 Display for AM2020/AFP-1010 Device Point Types
AFP-300/AFP-400
Device Point Type
NCA-2 Displays:
HEAT(ANALOG) HEAT
MULTISENSOR SMOKE(MULTI)
SUPERVISORY TRACK SUPERV
Table F.6 NCA-2 Display for AFP-300/AFP-400 Device Point Types
