84 NCA-2 Manual — P/N 52482:M5 03/20/2019
Programming Point Program Menu
.
Figure 5.44 Add Logic Function Screen
The cursor will be present in the logic equation. Place it, using the arrow keys on the keyboard, at the place where the logic function
should be inserted.
Soft Keys
LOGIC FUNCTION: Press to scroll through the list of possible logic functions.
ACCEPT: Press to insert the logic function into the equation where the cursor is blinking, and to return to the previous screen.
Add Time/Date
This screen appears when the ADD TIME/DATE soft key is pressed at the Logic Zone Programming Menu screen
Figure 5.45 Add Time/Date to Logic Zone Screen
Soft Keys
ENTER TIME: _ _:_ _:_ _ Press this soft key to toggle between the time/date formats. Choose one based on the type of time-based
function used.
Time-based
function
Screen Field Time/date format
DEL, SDEL, TIM ENTER TIME:_ _:_ _:_ _ HH:MM:SS, entered as military time (22:30:00 = 10:30 P.M.)
TIM ENTER DATE:_ _-_ _-_ _ (MM-DD-YY)
TIM ENTER DAY: MO
(Use the TOGGLE DAY soft key that appears to scroll through and choose a day of the
week.
LOGIC ZONE PROGRAMMING MENU
LOGIC ZONE ZLxxxx
AUTOMATIC OFF
AND(N01Z20,OR(N01L2D159,N01L2D14))
LOGIC FUNCTION: AND ACCEPT
BACK
LOGIC ZONE PROGRAMMING MENU
LOGIC ZONE ZLxxxx
AUTOMATIC OFF
DEL
OVERWRITE
ENTER TIME:22:30:00 ACCEPT
BACK
