NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005 23
Panel Program Program
REMINDER MENU: Press this soft key to bring up the Reminder Menu screen.
ACCEPT: Press this soft key to save the information entered on this screen.
MORE: Press this key to progress to the second Panel Settings screen.
Figure 3.6 Panel Settings (2) Screen
Soft Keys
LCM LOCAL MODE: Press this soft key to toggle between Yes and No. Enter Yes to enable all SLCs
to participate in local mode. When enabled, all LCMs will operate together in a limited fashion
when communication is lost with the NFS2-3030 CPU. Inputs on LCM loops (and associated LEM
loops, if installed) will activate outputs on all loops
• for those inputs and outputs that have been set with point programming to participate in local
mode, and
• when type codes are the same point type: that is, an input with a fire type code will activate an
output with a fire type code.(Refer to Appendix G, “Type Codes”, on page 127 for point types).
Default: NO
DCC PARTICIPATION: Press this key to program the panel for DCC (Display and Control Center)
participation. This network function ensures that one location at a time is in command of the
Acknowledge, System Reset, Signal Silence and Drill functions. Default: NO
LOCAL SETTINGS:Press this soft key to proceed to the Local Settings screen. Press the soft key
to scroll through the selections. The default is that there are no special local settings. Other settings
are explained in Appendix I, “Local Settings”.
DEFAULT SETTINGS: Press this soft key to activate default settings for the following:
PANEL SETTINGS
LCM LOCAL MODE: YES
DCC PARTICIPATION: NO
LOCAL SETTINGS ACCEPT
DEFAULT SETTINGS BACK
!
CAUTION:
On systems utilizing the DCC function, all locations that can participate in DCC should be set to YES.
Program setting for: Default:
Local Control Yes
Piezo On
Proprietary Supervising
Station
No
Event Ordering USA
Display Address Yes
LCM Local Mode No
DCC Participation No
