Message
associated with.. meaning.. ..possible action
DC too high / DC too
low
Power supply The DC supply is:
Too high if greater than 164 (32V)
Too low if less than 102 (20V)
Check the mains supply and battery wiring.
Delay block setup MCC / MCB
(main control card/board)
A Delay Block has been configured. -
Delay blocks Cleared MCC / MCB
(main control card/board)
--
Detection Zone
Disabled/Enabled at
card x
LPC
(loop processor card)
The detection zone has been enabled or disabled
automatically or manually.
If necessary, manually enable/disable the
detection zone using the [control] menu.
Detector on interface
unit number x on
loop y channel z
Device Conventional detector connected to an input of a mains
powered interface input has triggered. Value of the
input is equal to or less than 10V.
-
Device Address
changed from x
number y on loop z
Device Device SAFE address has changed. If necessary rectify the device SAFE address.
Device Battery Fault Radio (Plexus) Device Radio (Plexus) device has a battery failure Check the batteries at the Radio (Plexus) device
using the Battery Condition Indicator tool and
replace the batteries if necessary
Device batteries need
replacing
Radio (Plexus) Device The batteries inside a Radio (Plexus) device needs to
be replaced
Replace the batteries in the Radio (Plexus)
device
Device battery
discharged
Radio (Plexus) Device The batteries inside a Radio (Plexus) device are
nearing end of life.
Replace the batteries in the Radio (Plexus)
device
Device battery fault
/restored
Device The battery has failed the load test at the device, for a
mains powered interface the value is equal to or less
than normal - 2V.
Check and replace the battery if necessary.
Commissioning instructions
122 4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms.
Appendix B - Message Action List
