Message
associated with.. meaning.. ..possible action
Clock changed / Clock
not set up
MCC / MCB
(main control card/board)
Time and date has been altered or no time has been
entered.
If necessary, set the clock using the set up
menu.
CO sensor faulty Device There is a fault with the CO sensor in an S-Quad. Replace device
CO sensor near end of
life
Device The CO cell is nearing the end manufacturer
recommended life expectancy in an S-Quad.
Replace the device
CO sensor restored Device The CO sensor fault has been restored in an S-Quad -
Command build
activated /
deactivated
MCC / MCB
(main control card/board)
Command build has been switched ON (activated) or
switched OFF (deactivated).
If necessary switch ON/OFF the command
build using the [control] menu.
Command build enabled
/ disabled
MCC /MCB
(main control card/board)
This is an automatic or manually controlled action. If necessary, manually enable/disable the
command build using the [control] menu.
Comms enabled /
disabled at card x
MCC / MCB
(main control card/board)
Network Card
Card communications have been enabled or disabled.
Control panel has been isolated from the network.
If necessary, manually enable/disable the
Comms using the [control] menu
Comms Supply Fault Network node The communications power supply has failed. Replace the power supply unit.
Comms supply Restored Network node The communications power supply has been restored. -
Communications
started / stopped at
card x
MCC / MCB
(main control card/board)
Communication to a particular panel or to external
equipment linked to the panel (eg Laptop having the
commissioning tool) has started / stopped.
Check the wiring.
Control passed at
card x
Network - -
Corrupted NVM memory
at card x
Any Card Checksum failure on configuration at midnight. Recover data and record event in the log book.
If it reoccurs then replace the card.
DC Power fail /
restored
Power supply The ADC of output 27V regulator is
normally=146(28.5V).
-
4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms. 121
Vigilon 4/6 loops & Compact (VA) panels & network nodes
Appendix B - Message Action List
