Honeywell Vigilon 4 loop User Manual

Message
associated with.. meaning.. ..possible action
Warning cleared MCC / MCB
(main control card/board)
Warning has been removed. -
Wiring changed -
ground break at card
x number y on loop z
LPC
(loop processor card)
A test has shown a break on the 0V line. The test is
conducted every minute.
Check wiring of 0V around loop.
Wiring changed -
short at
card x number y
loop z
LPC
(loop processor card)
Loop short circuit after the particular device. Check wiring and device after indicated device.
Wiring changed -
split/closed at
card x number y on
loop z
LPC
(loop processor card)
No reply received from a device at End-2 of loop. Check wiring.
Wiring changed part
short at card x
number y on loop z
LPC
(loop processor card)
Less than 80 ohms between the +ve and 0V of loop
wiring.
Check wiring and the device after the partially
shorted device.
Wrong card type at
Card x
Any Card Card in wrong slot. Move the cards to the right location.
Zone enabled /
disabled at
card x
MCC / MCB
(main control card/board)
The zone has been enabled or disabled automatically or
manually.
If necessary, manually enable or disable the
zone using the [control] menu.
Commissioning instructions
138 4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms.
Appendix B - Message Action List
